Signal states, decoded bus values, and decoded protocols can be used to trigger a Logic Analyzer capture. Protocol groups can be used to view the decoded contents of packets of many common communications protocols, including SPI, I2C, UART, CAN, and I2S. Individual input/output channels can be grouped as buses and protocols. These channels are capable of interfacing with 3.3V and 1.2V logic signals, and when configured as inputs are tolerant of voltages of up to 5V. When used this way, the 16 digital input/output channels are configured to capture high/low logic states on connected pins at a sample rate of up to 125 MS/s.
DISCOVERY PRO MANUAL PRO
The Analog Discovery Pro (ADP3450/ADP3250) can be used with WaveForms' “Logic” instrument to act as a Logic Analyzer.
DISCOVERY PRO MANUAL GENERATOR
For a walkthrough of the different features of WaveForms' Waveform Generator instrument, please visit the Using the Waveform Generator guide. Since the Analog Discovery Pro's analog output channels are shared, the Waveform Generator instrument cannot be used at the same time as the Network Analyzer, or Impedance Analyzer instruments.įor more information on the analog output (“Wavegen”) channels, please visit the Analog Discovery Pro (ADP3450/ADP3250) Specifications. AC amplitudes of +-5V and DC offsets of +-5V are supported. Each channel has a bandwidth of >15MHz through the BNC connectors. Custom sets of samples can be defined by the user in applications like Excel and imported to WaveForms.Įach waveform generator channel is considered a single ended pin, however, a connected circuit must share a ground with the Analog Discovery Pro. The instrument supports everything from simple waveforms like Sine and Triangle waves, up to more complicated functions like AM and FM modulation. When the Waveform Generator instrument is used, the Analog Discovery Pro's analog output channels act as an Arbitrary Waveform Generator.
The Waveform Generator converts 14-bit digital samples to analog at a rate of up to 100 MS/s on each of the two channels.
The Analog Discovery Pro (ADP3450/ADP3250) can be used with WaveForms' Waveform Generator instrument to output analog voltage waves via BNC cables. USB Scopes, Analyzers and Signal Generators.
